Category
Daylight
Series
M-Series
Model
M-Series M18
Mains Plug
VEAM, Schaltbau (GTV-Standard)
Lamphead Type
Open Face with Facetted Reflector, 1,200 / 1,800 W
Reflector
MAX Technology reflector made of high purity aluminium
Lamp Type
Metal Halide 1,800 W/SE; Metal Halide 1,200 W/SE
Power Consumption
1,800 W / 1,200 W
Voltage Range
100 V / 140 V
Lamp Base
G38
Dimming
yes, 50 to 100 % via ARRI Ballast Unit
Correlated Color Temperature
6,000 K
Beam Angle
20° to 60° (with 1,800 W lamp)
Weight in kg net*
approx. 11.5 kg
Weight in kg packed*
approx. 14.9 kg
Weight in lbs. net*
approx. 25.36 lbs
Weight in lbs. Packed*
approx. 32.85 lbs
Measurements (HxWxL) incl. Pin in mm*
658 x 388 x 393 mm
Measurements (HxWxL) excl. Pin in mm*
525 x 388 x 393 mm
Measurements (HxWxL) incl. Pin in inch*
25.9 x 15.3 x 15.5"
Measurements (HxWxL) excl. Pin in inch*
20.7 x 15.3 x 15.5"
Measurements (HxWxL) Packed size in mm*
530 x 510 x 555 mm
Measurements (HxWxL) Packed size in inch*
20.9 x 20.1 x 21.9"
Lens / UV-Protection Glass Diameter in mm
276 mm
Lens Diameter in inch
16.8"
Accessory Diameter in mm
330 mm
Accessory Diameter in inch
13.0" (Scrim)
Barndoor in mm
344 mm
Barndoor in inch
13.5"
Mounting
Spigot 28 mm / 1 1/8" (1.1")
Housing Color
Blue/Silver
Protection Class / IP Rating
I / IP23
Certifications
CE, CB, ENEC, cNRTLus
Note *Weight and dimensions are rounded values.
